In this guide, we show how to deploy DeepSeek-R1 with SGLang on 8x NVIDIA H200 GPUs, which are available on-demand through the DataCrunch Cloud Platform, and run a performance benchmark.
Inference engine: SGLang
SGLang is the recommended inference engine for deploying DeepSeek models, in particular DeepSeek-V3/R1. SGLang currently supports MLA optimizations, DP Attention, FP8 (W8A8), FP8 KV Cache, and Torch Compile, enabling it to deliver state-of-the-art latency and throughput performance among other open-source frameworks.
Notably, SGLang v0.4.1 fully supports running DeepSeek-V3 on both NVIDIA and AMD GPUs, making it a highly versatile and robust solution. SGLang also supports multi-node tensor parallelism, enabling you to run this model on multiple network-connected machines.
Multi-Token Prediction (MTP) is in development, and progress can be tracked in the optimization plan (e.g. FusedMoE H200 aware-tuning) and custom kernels development.
We have been providing the SGLang team with GPU infrastructure targeting H200 aware-tunning for optimal performance. (see H200 DeepSeek V3/R1 benchmarking).
Deploying DeepSeek-R1
- The original sglang docker image is used as recommended:
docker pull lmsysorg/sglang:latest
- The following command will create a valid docker container to host
DeepSeek R1.
- It is needed to mount a volume with the location of the huggingface cache folder. By default is:
~/.cache/huggingface - It is needed to specify our
HF_TOKENto access the huggingface API. It can be exported as an environment variable as seen in--env "HF_TOKEN=$HF_TOKEN"
docker run --gpus all \
--shm-size 32g \
--network=host \
-v ~/.cache/huggingface:/root/.cache/huggingface \
--name deepseek_r1 \
-it \
--env "HF_TOKEN=$HF_TOKEN" \
--ipc=host \
lmsysorg/sglang:latest \
bash
- This will create an interactive session inside the container where the following command should launch the server with
DeepSeek R1.
python3 -m sglang.launch_server --model deepseek-ai/DeepSeek-R1 --tp 8 --trust-remote-code --enable-dp-attention
Benchmarking DeepSeek-R1
- The following command will perform a benchmark workload for 1 batch, 128 inputs token, and 256 outputs token:
python3 -m sglang.bench_one_batch --batch-size 1 --input 128 --output 256 --model deepseek-ai/DeepSeek-R1 --trust-remote-code --tp 8 --enable-torch-compile --torch-compile-max-bs 1
Prefill. latency: 1.91032 s, throughput: 67.00 token/s
Decode. latency: 1.04900 s, throughput: 0.95 token/s
Decode. latency: 0.02175 s, throughput: 45.99 token/s
Decode. latency: 0.02097 s, throughput: 47.69 token/s
Decode. latency: 0.02097 s, throughput: 47.68 token/s
Decode. latency: 0.02080 s, throughput: 48.07 token/s
Decode. median latency: 0.02097 s, median throughput: 47.68 token/s
Total. latency: 3.086 s, throughput: 44.07 token/s
Benchmark ...
Prefill. latency: 0.19635 s, throughput: 651.90 token/s
Decode. latency: 0.02100 s, throughput: 47.62 token/s
Decode. latency: 0.02078 s, throughput: 48.13 token/s
Decode. latency: 0.02092 s, throughput: 47.80 token/s
Decode. latency: 0.02086 s, throughput: 47.93 token/s
Decode. latency: 0.02085 s, throughput: 47.97 token/s
Decode. median latency: 0.02098 s, median throughput: 47.67 token/s
Total. latency: 5.537 s, throughput: 69.35 token/s
Two benchmarks are run as sanity checks. The final user will perceive the decode latency as shown below:
Decode. median latency: 0.02098 s, median throughput: 47.67 token/s
